5
Setup with G0375A and G0376A for PRBS31Q Error Free
32Gbaud Power PAM4 Converter
G0375A
32Gbaud PAM4 Decoder with CTLE
G0376A
32G 2ch SI PPG
MU195020A
(Opt-020, 021, 031)
32G 2ch SI ED
MU195040A
(Opt-020, 022)
CTLE Input
Decoder Input
Signal Quality Analyzer-R
MP1900A
J1741A cable x4
(80 cm, skew <1 ps)
J1728A cable x2 (40 cm, skew <1 ps)
J1728A cable x2 (40 cm, skew <1 ps)
(*1) Cable x2 (skew <1 ps)
(*1) J1728A or lower loss cable
Synthesizer
MU181000B
Jitter Modulation
MU181500B
DUT
J1439A
80 cm, K cable
41KC-6 x4
To Next Page
