Specifications Tx
G0375A 32Gbaud Power PAM4 Converter + MU195020A 21G/32G bit/s SI PPG
Item Specification Remarks
Number
of Outputs
2
(Data, xData)
AC coupling
Baud Rate
10
to 32.1 Gbaud
Output
Amplitude
0.3 to 1.95
Vp-p (Single-end, typ.)
Data1 input 0.2 to 1.3 Vp
-p and
Data2 input 0.1 to 0.65 Vp
-p
Random Jitter (rms)
200 fs (typ.)
Tr/Tf (20% to 80%)
14 ps (typ.)
Using MU195020A
SI-PPG
Eye Linearity
(RLM)
0.6 to 1 adjustable from level ratio
Number
of Inputs
4 (Data1, xData1, Data2, xData2)
Uses Data3
and J1735A (two for
differential)
at 3 Eye independent
level control
Maximum Input
Amplitude
1.5 Vp
-p (Data1, xData1)
0.75 Vp
-p (Data2, xData2)
In/Out
Connector
K
(female)
