Configuration Guide
l
MT1000A 3
3. Example Configurations
This is the base configuration for users requiring all interfaces up to 2.7 Gbps and 10 GigE single channel.
Note: This configuration supports single-channel 10 GigE operation on either physical port while testing separately at up to 2.7 Gbps on the other port simultaneously.
Required Configuration
Model/Order No. Name Remarks
MT1000A Network Master Pro Mainframe
MU100010A 10G Multirate Module 10G Module
MU100010A-001 Up to 2.7G Dual Channel 2.7 Gbps Interface Max. (OTU1, ~1 GigE, ~STM-16/OC-48)
MU100010A-011 Ethernet 10G Single Channel 10G Ethernet Interface
This configuration is for testing from the OTU2 Physical interface to GigE client signals using dual stage multiplexing.
Required Configuration
Model/Order No. Name Remarks
MT1000A Network Master Pro Mainframe
MU100010A 10G Multirate Module 10G Module
MU100010A-001 Up to 2.7G Dual Channel 1 GigE Payload Client
MU100010A-051 OTN 10G Single Channel 10 Gbps OTN Interface
MU100010A-061 ODU Multiplexing Dual Stage Multiplexing (OTU2 – ODU1 – ODU0 – 1 GigE)
This configuration is for testing from the OTU2e/1e Physical interface to 10 GigE client signals simultaneously on two ports.
Required Configuration
Model/Order No. Name Remarks
MT1000A Network Master Pro Mainframe
MU100010A 10G Multirate Module 10G Module
MU100010A-012 Ethernet 10G Dual Channel 10 GigE Payload Client (Dual Channel)
MU100010A-052 OTN 10G Dual Channel 10 Gbps OTN Interface (Dual Channel)
This is the maximum configuration for testing all interfaces (includes WLAN and extended warranty).
Using this configuration, any two OTN/10 GigE/CPRI/OBSAI/SDH/FC (1G to 10G) channels can be combined at two Physical ports for simultaneous
operation.
Required Configuration
Model/Order No. Name Remarks
MT1000A Network Master Pro Mainframe
MU100010A 10G Multirate Module 10G Module
MU100010A-001 Up to 2.7G Dual Channel 2.7 Gbps Interface Max. (OTU1, ~1 GigE, ~STM-16/OC-48)
MU100010A-012 Ethernet 10G Dual Channel 2 × 10 Gbps Ethernet Interfaces (simultaneous)
MU100010A-020 TCP Throughput RFC 6349 testing
MU100010A-052 OTN 10G Dual Channel 2 × 10 Gbps OTN Interfaces (simultaneous)
MU100010A-061 ODU Multiplexing Multiplexing between OTN mappings (OTU2 – ODU1, or OTU2 – ODU1 – OTU0)
MU100010A-062 ODU Flex Flex Mapping (OTU2 – ODUex)
MU100010A-082 STM-64 OC-192 Dual Channel 2 × 10 Gbps SDH/SONET Interface (simultaneous)
MU100010A-071
CPRI/OBSAI Up to 5G
Dual Channel
2 × CPRI/OBSAI Interfaces (Up to 5G) (simultaneous)
MU100010A-073
CPRI/OBSAI 6G to 10G
Dual Channel
2 × CPRI/OBSAI Interfaces (6G to 10G) (simultaneous)
MU100010A-002 FC 1G 2G 4G Dual Channel 2 × FC Interfaces (1G to 4G) (simultaneous)
MU100010A-092 FC 8G 10G Dual Channel 2 × FC Interfaces (8G to 10G) (simultaneous)
MT1000A-003 Connectivity for WLAN/Bluetooth
Supports remote control over WLAN and le copying over WLAN/Bluetooth
This option supports WLAN/Bluetooth.
(Available for certied countries and regions including USA, Canada, Japan and all EU countries.
Refer to the Anritsu website for the latest information.)
MT1000A-ES210
2 Years
Extended Warranty Service
Mainframe Warranty Service Extension
(1 year (standard) + 1 year = 2 years warranty service)
MU100010A-ES210
2 Years
Extended Warranty Service
10G Multirate Module Warranty Service Extension
(1 year (standard) + 1 year = 2 years warranty service)
The Bluetooth
®
mark and logo are registered trademarks of Bluetooth SIG, Inc.
