5
Select testing requirements
Select Dynamic Range
Select the model with the required
test wavelength and dynamic range
from 2-2-1 Selecting Dynamic Range.
Page 10
With/Without Visible Light Source
Select the model with built-in visible
light source if required from 2-2-3
Selecting Visible Light Source Option.
Page 10
Select Connector
Select the model with the required
connector type from 2-2-2 Selecting
Polish Type/Connector Adapter.
Page 10
Choose MU100021A
Page 10
Unit size:
1U/4U
MU100010A
MT1000A
MU100010A
MU100021A
MT1000A
MU100010A
MU100021A
MU100090A
MT1000A
Module Combination Example
Select Module Options
Select the model for choosing the
measurement spectrum.
3-2 Selecting Module Options.
Page 13
Select RF over CPRI Test Options
Select the model for choosing the
required options from 3-3 Selecting
MU100040A Options.
Page 13
Choose MU100040A
Page 13
(3) CPRI RF
Unit size:
1U/4U
