2. System Connections
VectorStar MN469xC QSG PN: 10410-00738 Rev. C QSG-5
Table 1. MN469xC Multiport Semi-Rigid Cable Interconnect Part Numbers and Locations (1 of 2)
Index Part Numbers Description/Torque Connection From Connection To
Front Panel Connections
1
3-62109-42
V (m-m)
(MN4697C)
-or-
3-67357-38
K (m-m)
(MN4694C)
Front Panel RF Cable (8 each)
V or K male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
VNA port labeled:
b1 (In)
MN469xC port labeled:
b1 (In)
VNA port labeled:
b1 (Out)
MN469xC port labeled:
b1 (Out)
VNA port labeled:
Port 1 Source (In)
MN469xC port labeled:
Port 1 Source (In)
VNA port labeled:
Port 1 Source (Out)
MN469xC port labeled:
Port 1 Source (Out)
VNA port labeled:
Port 2 Source (In)
MN469xC port labeled:
Port 2 Source (In)
VNA port labeled:
Port 2 Source (Out)
MN469xC port labeled:
Port 2 Source (Out)
VNA port labeled:
b2 (In)
MN469xC port labeled:
b2 (In)
VNA port labeled:
b2 (Out)
MN469xC port labeled:
b2 (Out)
Rear Panel Connections
2 3-62112-81
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
b2 loop out
MN469xC port labeled:
TO VNA b2 OUTPUT
3 3-62112-80
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
b2 loop in
MN469xC port labeled:
TO VNA b2 INPUT
4 3-62112-81
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
P2 Source loop out
MN469xC port labeled:
TO VNA Port 2 Src
OUTPUT
5 3-62112-80
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
P2 Source loop in
MN469xC port labeled:
TO VNA Port 2 Src
INPUT
6 3-62112-81
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
b1 loop out
MN469xC port labeled:
TO VNA b1 OUTPUT
7 3-62112-80
SMA male-male semi-rigid
Tighten using an 8 mm (5/16 in)
torque end wrench set to 0.9 N·m
(8 lbf·in).
MS464xB port labeled:
b1 loop in
MN469xC port labeled:
TO VNA b1 INPUT
