www.ansmann-racing.com
VIRUS 3.0 |
D
Bedienungsanleitung |
Instruction Manual
8
2.4 | MONTAGE HINTERACHSE 2.4 | REAR SUSPENSION ARMS ASSEMBLY
Schraubensicherungslack
Thread Lock
16.5
Round head selftaping screw 3x10
Screw shaft M5x5
Set screw 3x18
4x
2x
2x
4150-0006
191000020
4150-0034 4150-0041
4150-0041
4150-0009
4150-0030
4150-0005
4150-0023
4150-0043
4150-0031
4150-0031
(M5x5)
(3x18)
(M3x15)
(3x10)
Schraubensicherungslack
Thread Lock
16.5
4150-0006
191000020
4150-0034
4150-0041
4150-0041
4150-0009
4150-0030
4150-0005
4150-0023
4150-0043
4150-0031
4150-0031
(M5x5)
(3x18)
(M3x15)
(3x10)
4150-0001_manual_virus3_kit_12-08.indd 8 05.09.12 14:45
