SUPPORT STAND DIMENSIONS
Page 4
FIGURE 3
006008
26 1/8 IN.
(
66.4 cm)
27 1/2 IN.
(
69.9 cm)
22 1/2°
20 1/4 IN.
(51.4 cm)
14 IN.
(35.6 cm)
11 1/2 IN.
(
29.2 cm)
1
/2 IN. DIAMETER
MOUNTING HOLES (8 PL)
4 1/4 IN.
(10.8 cm)
