FIGURE 4
006009
OSCILLATING MECHANISM DETAILS
Page 5
OSCILLATING MECHANISM
G
REASE FITTINGS
WOM-3 BASE COUPLING
G
REASE FITTING (TO
ACCESS ROTATE 90° RIGHT)
CLEVIS
A
SSEMBLY
FRONT ADJUSTMENT
NUTS (OSCILLATION ARC)
REAR ADJUSTMENT NUTS
(OSCILLATION ARC)
GARDEN
HOSE
C
ONNECTION
BRASS
CYLINDER
END-STOP TUBE “A”
(ARC ADJUSTMENT)
END-STOP TUBE “B”
(ARC ADJUSTMENT)
FOUR-WAY
VALVE
SPEED
CONTROL
FILTER
CLEAN-OUT
TEST GAUGE
CONNECTION
SELECTOR
VALVE IN “RUN”
POSITION
SELECTOR VALVE
IN “TEST/MANUAL”
POSITION
