10
first channel from which the machine will respond to the controller. Always double check to
make sure there are no overlapping channles in order to control the machine correctly.
DMX Channel Function
Z-3 Remote Control Operation (Optional)
To operate the machine by remote control, connect the remote to the microphone jack
located on the rear of machine. Use the switch to turn fog on/off, and use the rotary knob to
adjust the output volume from 0~100%.
WTR-20 Wireless Operation (Optional)
Wireless remote control system WTR-20 consists of a transmitter equipped with four buttons to
activate, deactivate, increase and decrease fog output and an onboard receiver attached to the
rear panel of FT-20X fog machine.
