Antari M-5 - Technical Specifications; Control Module Operation; M-20 Remote Control Functions

(M-20)
M-20 M-30
Fluid level sensor is installed on the unit. The machine ‘s pump will automatically
stop working if the fluid is lower than usable level. It will re-start when
temperature reaches working level Always monitor tank fluid level as you are
operating making sure there’s sufficient liquid in the tank..
M-20:
M-20
Of the above appears to be O.K., plug the unit again. If fog does not come out, check
the hose attached to the tank to make sure there is fluid going through the hose. If you
are unable to determine the cause of the problem, do not simply continue pushing the
remote button, as this may damage the unit. Return the machine to your Antari dealer.
- Input voltage
- Rated power
- Warm-up time
- Fluid consumption
- Fluid tank capacity
- Compatible fluid
- Ambient temp. range
- Output
- Control
- DMX channels
- Connection
- Optional accessories
- Dimension
- Weight
US model : AC 100-120V, 50 / 60Hz 12.5A
EU model : AC 220-240V, 50 / 60Hz 6.6A
1500W
8 minutes (approx.)
160 ml/min
10l (2.64gal)
Antari FLG-10 Heavy Fog Fluid
Antari FLR-10 Light Fog Fluid
0°C - 40 °C (32°F-104 °F)
3 3
25,000 ft /min (708 m /min)
DMX512, Timer, Manual,
Wireless (Optional)
1 channel
Neutrik Powercon (Power)
XLR 3-pin and 5-pin (DMX)
M-30 Pro Wireless Control Module
FX-5 Flightcase
M-5-HB Hanging Bracket
L668 W320 H276 mm
(L26.30 W12.60 H10.87 inch)
15.5 kg (34.17 lbs)
EU model : AC 220-240V, 50 / 60Hz 13A
3000W
9.5 minutes (approx.)
250 ml/min
10l (2.64gal)
Antari FLG-10 Heavy Fog Fluid
Antari FLR-10 Light Fog Fluid
0 °C - 40 °C (32 °F-104 °F)
3 3
50,000 ft /min (1416 m /min)
DMX512, Timer, Manual,
Wireless (Optional)
1 channel
Neutrik Powercon (Power)
XLR 3-pin and 5-pin (DMX)
M-30 Pro Wireless Control Module
FX-5 Flightcase
L690 W320 H298 mm
(L27.17 W12.60 H11.73 inch)
21 kg (46.30 lbs)
