6
M-30
M-30:
M-20
M-20
M-30
All fog machines develop condensation around the output nozzle. This may result in some
moisture accumulation on the surface below the output nozzle, gently wipe it clean. If
abnormal condensation is detected, please check your choice of fog liquid due to impurity.
Kindly stop using to ensure life span of the machine.
7
Maintenance / Storage
Do not allow the fog liquid to become contaminated. Always replace the caps on the fog
liquid container and the fog machine liquid tank immediately after filling. Do not operate
the fog machine without liquid at any time.
Clean with a dry cloth only. Store dry. Cleaning your fog machine regularly will help
reduce costly replacement and repair charges.
Note: All fog machines are prone to clogging due to the thick consistency of fog liquid
and the high temperature at which it vaporizes. It is strongly recommended that to
do regular maintenance and services. A properly maintained fog machine should
provide years of reliable use.
It is strongly recommended to test-run the machine on a monthly basis in order to
achieve its best fogging condition. A test-run consists of warming up the machine
followed by a few minutes of emission. Then please cool down the machine.
Please read and save these instructions.
Pin
Function
1
2
3
Ground
Data -
Data +
3 pin XLR 5 pin XLR
2 1
3
5 1
24
3
1 5
42
3
1 2
3
DMX Connector Pin Assignment
The machine provide 3 or 5 pin XLR connector for DMX connection. Diagram below
indicate pin assignment information
