MODULAR CABLE JACKS
Caution: Please connect only cables provided with this EDG650. Other cables may not be compatible!
Please mount the PSU carefully into the case, if you are using the Anti-Noise De-Couplers. Some
cases might be incompatible with them.
18+10-pin MBU connection
You can connect 1 or 2 modular 8-pin cables into any of the 16-pin sockets
TABLE 2
Cable Quantity
Connectors
Socket
Description
1
X 1
18-pin & 10-pin
24(20+4)-pin Motherboard
1
X 1
8-pin
8(4+4)-pin ATX12V/EPS12V
2
X 2
8-pin
8(6+2)-pin PCI-E
1
X 4
5-pin
Molex + FDD
X 1
2
X 4
5-pin
SATA
1
X 2
5-pin
Molex
X 1
Molex
