Antec One - Chassis Specifications

6
1.2 Chassis Specifications
Chassis Type
Mid Tower
Chassis Color
Black
Dimensions
17.2” (H) x 8.2” (W) x 19.2” (D)
438 mm (H) x 208 mm (W) x 488 mm (D)
Weight
One: 10.8 lbs / 4.9 kg
One S / One S3: 10.4 lbs / 4.7 kg
Cooling
One:
- 1 x 120 mm top exhaust fan
- 1 x 120 mm rear exhaust fan
- 1 x 120 mm side intake fan (optional)
- 1 x 120 mm front intake fan (optional)
- 1 x 120 mm / 140 mm bottom fan (optional)
One S / One S3:
- 1 x 120 mm top blue LED exhaust fan
- 1 x 120 mm rear exhaust fan (optional)
- 1 x 120 mm side intake fan (optional)
- 1 x 120 mm front intake fan (optional)
- 1 x 120 mm / 140 mm bottom fan (optional)
Drive Bays
- 3 x 5.25” tool-less drive bays
- 5 x 3.5” tool-less drive bays
- 2 x 2.5” drive-bays
Expansion Slots
7
Motherboard Size
Standard ATX, microATX, Mini-ITX
Front I/O Panel
- Audio In/Out
- Power and Reset buttons
One / One S3:
- 2 x USB 3.0 with internal motherboard connector
One S:
- 2 x USB 2.0 ports
