10
C
OOLING
S
YSTEM
4.1
T
RI
C
OOL
™
F
ANS
Rear / Top TriCool™ Fans – There is one rear 120mm and two top 140mm TriCool™ fans pre-installed in
the case. They have external, three-speed switches that let you choose between quiet, performance, or
maximum cooling on each of the fans. The default speed setting is Low. The two fans are mounted so
that the air is exhausting from the case. There are externally accessible switches for these fans located at
the top rear of your case.
120mm TriCool™ Specifications:
Size: 120 x 25mm TriCool™ fan
Rated Voltage: 12V
Operating Voltage: 10.2V - 13.8V
Speed
(RPM)
Input
Current
Air Flow
Static
Pressure
Acoustic
Noise
Input
Power
High
2000
0.24A
(Max.)
2.2 m³ / min
(79 CFM)
2.5mm-H2O
(0.10 inch-H2O)
30 dBA 2.9W
Medium
1600
0.20A
1.6 m³ / min
(56 CFM)
1.5mm-H2O
(0.06 inch-H2O)
28 dBA 2.4W
Low
1200
0.13A
1.1 m³ / min
(39 CFM)
0.9mm-H2O
(0.04 inch-H2O)
25 dBA 1.6W
140mm TriCool™ Specifications:
Size: 140 x 25mm
Rated Voltage: DC 12V
Operating Voltage: 10.2V ~ 13.8V
Speed
(RPM)
Input
Current
Air Flow
Static
Pressure
Acoustic
Noise
Input
Power
High
1500
0.28A
(Max.)
2.7 m³ / min
(94.6 CFM)
1.7mm-H2O
(0.07 inch-H2O)
32 dBA 3.4W
Medium
1100
0.20A
1.9 m³ / min
(66.8 CFM)
0.9mm-H2O
(0.04 inch-H2O)
21 dBA 2.4W
Low
700
0.15A
1.33 m³ / min
(47 CFM)
0.4mm-H2O
(0.02 inch-H2O)
20 dBA 1.8W
