Discrete 8 Synergy Core User Manual
Page 73
• To c o m p l e t e l y t u r n o f f t h e d e v i c e , u n p l u g t h e p o w e r c a b l e f i r s t f r o m t h e o u t l e t
and then from the rear panel of the unit.
• Both occasional and continued exposure to high sound pressure levels can cause
permanent ear damage via headphones and monitors.
• Your unit shoul d always be un-racked when traveling or in a flight case.
• The device is designed to operate in a temperate environment, with a correct
Operating Temperature of 0-50° C, 32-122° F.
14. TECHNICAL SPECIFICATIONS
Analog Inputs
6 x Mic / Line Inputs
2 x Mic / Line / Hi-Z Inputs
Analog Outputs
2 x Monitor Out on TRS 1/4 Jacks, +20 dBu
max (switchable to REAMP outputs)
8 x Line Outs on TRS, +20 dBu max, DC-
Coupled
2 x Stereo Headphone Outputs!
Mic Preamp
!
EIN: -128 dBu (A-weighted)
Dynamic Range: -121 dB (A-weighted)
THD: -106 dB
Max input: +18 dBu
Max Gain: 65 dB
D/A Monitor Converter
Dynamic Range: 130 dB
THD + N: -115 dB
A/D Converter
Dynamic Range: 121 dB
THD + N: -112 dB
D/A Converters (Line Out)
!
Dynamic Range: 118dB
