Access Control Power Supply
Wiring Connection
Exit Button
Door Sensor
Magnetic Lock
FR 107
+
-
+12 GND GNDNO NCPUSH
SC021 and the FaceDeep5 device are
authorized by Anviz wiegand to form a
distributed access control system.
Please contact sales@anviz.com for
more information.
SC021
Exit Button
Magnetic Lock
GND 12V
FCARD MICROPOWER
POWER SUPPLY CONTROLLEF
MODEL:FC-901/903
INPUT:AC220/230W 50HZ
OUTPUT:DC12V, 3Amps+
