ACT-5X+ Exciter User Manual
Version 1.1 5/8/2015 Page 17 of 33
Table 11 CONFIG Menu
*ID
bps
IP
GATEWAY
MASK
UPGRADE
Default
ID: 80H
19200
192.168.001.1
43
192.168.001.0
01
255.255.255.00
0
NO
Options
ID: 00H
19200
***.***.***.*
**
***.***.***.*
**
***.***.***.**
*
NO
ID: 01H
9600
YES
...
38400
ID: FEH
ID: FFH
Note:
1) "IP", "GATEWAY", and "MASK" are used to establish a valid Ethernet connection for remote control
via the REMOTE RJ45 located on the rear panel. The exciter has a built-in WEB GUI which requires
only a standard web browser run by a PC. Simply by entering specified IP address, which is setup in
CONFIG sub-menu, in a browser’s address bar, the login interface will pop up and give user prompts
to input the user name and password. There are two tiers of web interface available. The first “guest”
tier is limited in monitoring and control, allowing users to retrieve information such as SNR and
shoulder measurements, user configuration, and alarms. The guest account is accessed with a user
name and password of "guest" and "guest" (case sensitive). The second “admin” tier provides full
status and control of the exciter/translator and is accessed with a username and password of
“anywavecom" and "anywavecom" (case sensitive).
2) "UPGRADE" is a reserved mode to perform an upgrade of the code inside the exciter/translator unit.
Table 12 TSoIP Network Menu
Welcome to TS_NET interface!
IP
MASK
GATE
MUTI
MISC
Default
192.168.001.200
255.255.255.000
192.168.001.001
235.100.001.001
Options
***.***.***.***
***.***.***.***
***.***.***.***
***.***.***.***
Note:
1) The "IP" submenu defines the physical IP address of TSoIP module
2) The “MASK” submenu defines the network mask of TSoIP module
3) The “GATE” submenu defines the network gateway/route of TSoIP module
