ACT-5X+ Exciter User Manual
Version 1.1 5/8/2015 Page 8 of 33
2 Operation Specifications
 Environment
 Operating Temperature: -10 ~ 50
o
C
 Operating Humidity: ≤ 95%
 Atmospheric Pressure: 86 kPa ~ 106 kPa
 Power Supply
 Voltage: 88 ~ 264 VAC
 Frequency: 50 / 60 Hz
 Inputs/Outputs
 RF_IN_A /RF_IN_B (AGC RF Feed-Back option via RF IN A)
 Connector: BNC female
 Impedance: 50 Ω
 Level: -30 dBm ~ 0 dBm
Recommended range: -15 dBm ~ -5 dBm
 Location: Back Panel
 AGC_IN (AGC DC Feed-Back option)
 Connector: BNC female
 Impedance: 50 Ω
 DC Voltage: 0 V ~ 5 V
 Location: Back Panel
 RF_OUT
 Connector: N-type female
 Impedance: 50 Ω
 Level: -25 dBm ~ +5 dBm
 VSWR: > 15 dB
 Location: Back Panel
 RF_MON (loop out of [RF_OUT])
 Connector: BNC female
 Impedance: 50 Ω
 Level: 10 dB below [RF_OUT]'s output level
 Location: Back Panel
 10M_IN
 Connector: BNC female
 Impedance: 50 Ω
 Level: AC-coupled, V
P-P
≥ 300 mV
 Location: Back Panel
