ACT-5X+ Exciter User Manual
Version 1.1 5/8/2015 Page 9 of 33
1PPS IN
Connector: BNC female
Impedance: 50 Ω
Level: 3.3 V-TTL
Input trigger: Positive Transition
Location: Back Panel
10M OUT
Connector: BNC female
Impedance: 50 Ω
Level: 0 dBm
Location: Back Panel
1PPS OUT
Connector: BNC female
Impedance: 50 Ω
Level: 3.3 V-TTL
Location: Back Panel
TS_IN_1A/ TS_IN_1B
Connector: BNC female
Impedance: 75 Ω
Level: See Table 1
Location: Back Panel
TS_OUT
Connector: BNC female
Impedance: 75 Ω
Location: Back Panel
TUNER_IN
Input level range: -80 dBm ~ - 15 dBm
Input connector: BNC female, 50 Ω
TSoIP OUT
Connector: BNC female
Impedance: 75 Ω
Location: Back Panel
GPS ANT
Connector: BNC female
Impedance: 50 Ω
Location: Back Panel
Table 1 ASI Input Specifications
No
Content
Unit
Value
1
Input Level
mv
200
2
Positive Transition (20%~80%)
ps
1200
