ACT-5X+ Exciter User Manual
Version 1.1 5/8/2015 Page 19 of 33
3.4 Advanced Menu
To enter the Advanced Menu, first enter the User Menu by pressing the both "Left" and "Right"
buttons at the same time to arrive at the menu shown below.
Table 15 User Menu
Welcome to setting interface!
*SYSTEM
RF
NETWORK
MODE
CONFIG
Then, press both the "Up" and "Down" buttons at the same to enter Advanced Menu, as shown
below.
Table 16 Advanced User Menu
Welcome to advanced interface!
*AD1
MUTE
AD3
DPD
SN
D&T
PAC
Table 17 through Table 23 show the corresponding sub-menus.
Table 17 AD1 Menu
PCRL
Sw_Up
Sw_Down
SW_RT
PAC
Default
1
OFF
OFF
03
RF
Options
0: Null packet
deletion ON
but NO PCR
ON
ON
03~FF
RF
1: Null packet
deletion ON
and PCR ON
OFF
OFF
DC
2: NO null
packet deletion
and NO PCR
3: NO null
packet deletion
but PCR ON
