AOC 2036S User Guide

- 29 -
• The Computer Video Card should be snugly fitted in its slot.
• Make sure the monitor's video cable is properly connected to the computer.
• Inspect the monitor's video cable and make sure no pin is bent.
• Make sure your computer is operational by hitting the CAPS LOCK key on the
keyboard while observing the CAPS LOCK LED. The LED should either turn
ON or OFF after hitting the CAPS LOCK key.
Missing one of the primary
colors (RED, GREEN, or
BLUE)
• Inspect the monitor's video cable and make sure that no pin is damaged.
• Make sure the monitor's video cable is properly connected to the computer.
Screen image is not
centered or sized properly
• Adjust H-Position and V-Position or press hot-key (AUTO).
Picture has color defects
(white does not look white)
• Adjust RGB color or select desired color temperature.
Horizontal or vertical
disturbances on the screen
• Use Windows 95/98/2000/ME/XP shut-down mode Adjust CLOCK and
FOCUS.
• Press to auto-adjust.

AOC 2036S Specifications

General

Pixel pitch	0.2768 x 0.2768 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size diagonal	508.05 mm
Contrast ratio (dynamic)	60000:1
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Power requirements	90 - 240V, 50 - 60Hz
Display viewable area (HxV)	442.8 x 249.075 mm
AC (power) in	Yes
USB hub version	2.0
DVI-I ports quantity	0
Power consumption (standby)	1 W
Power consumption (typical)	25 W
Certification	FCC, CE, CB, CCC, CUL, TUV/S, TUV-Bauart, ROHS, EPEAT, ISO13406-2
Product color	Black
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	- mm
Package depth	130 mm
Package width	558 mm
Package height	356 mm
Package weight	5900 g

Weight and Dimensions

Depth (without stand)	186 mm
Width (without stand)	496.5 mm
Height (without stand)	378.66 mm
Weight (without stand)	4500 g
