AOC 2036Sa Service Manual

46
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp for the latest information.
2036S TA9SMGNK6WA2QN
Location Part No. Description
040G 58162461A EPA LABEL
052G 1186 SMALL TAPE
052G 1207 A CONDUCTIVE TAPE 45MM *25MM *0.08MM
052G 1208 A ALUMINIUM TAPE
052G 1211550 ALUMINUM FOIL TAPE
052G 2191 A PAPER TAPE
089G 175 8 X USB CABLE 1.8M
089G 725CAA DB D-SUB CABLE
089G402A15N IS POWER CORD
095G8014 5XH09 HARNESS 5P(PLUG)-5P(2501) 200MM
095G8014 7X588 HARNESS 7P(PLUG)-6P(C2003) 340MM
095G8018 3XH18 LVDS CABLE 30P-30P 140MM
095G8022 6X504 HARNESS 6P-6P 200MM
0M1G 130 5120 SCREW
0M1G1730 6120 SCREW,42-D020523
0M1G1730 6120 SCREW,42-D020523
0M1G1730 6120 SCREW,42-D020523
0M1G1730 6120 SCREW,42-D020523
705GQ934011 20" LCD STAND BASE ASS'Y
0Q1G1040 8120 SCREW
Q01G6064 1 SCREW
Q12G6600 6 FOOT
Q34G0560AED 1S0100 AOC-836 STAND_FRONT
Q34G0561AED 1S0100 AOC-936 STAND_REAR
Q34G0562AED 1S0130 AOC-936 BASE
Q37G0133012 HINGE
750GLS200KT312N000 PANEL LTM200KT03 802(V02) SZ SEC
756GQ8CB AA083 MAIN BOARD-CBPCRMGA1QY
U402 056G1133129 IC EN25F20-100GCP 2MB SOP-8
SMTCR-U402 100GAMSA002N41 MCU ASS'Y-056G1133129
040G 45762412B CBPC LABEL
CN409 033G3802 7B Y CONNECTOR 7P 2.0 DIP
CN404 033G3802 9B Y CONNECTOR 9P 2.0
CN405 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
R480 061G152M229 64 2.2 OHM 2W 5% MOF
CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW
X401 093G 22 53 J 14.31818MHZ/32PF/49US
709G3244 QM001 CONSUMPTIVE ASS'Y
055G 2 ALCOHOL
055G 23524 WELDING FLUX WITHOUT PB
Q55G 100625 TIN STICK_LOW ARGENTUM
C410 067G 2151007RT LOW E.S.R 10UF +/-20% 50V
C427 067G 305101 4T 100UF +-20% 25V
C423 067G 305101 4T 100UF +-20% 25V
C426 067G 305101 4T 100UF +-20% 25V
C421 067G 305101 4T 100UF +-20% 25V
U401 056G 562560 IC TSUMU18ER-LF LQFP-64 MSTAR
U404 056G 563 52 IC AP1117D33L-13 TO252-3L DIODES
U103 056G 662502 IC ESD AZC199-04S SOT23-6L
U102 056G 662502 IC ESD AZC199-04S SOT23-6L
U402 056G1133129 IC EN25F20-100GCP 2MB SOP-8
