AOC 2036Sa Service Manual

5
1. Monitor Specifications
LCD Panel
Model number 2036S&2036Sa
Driving system TFT Color LCD
Viewable Image Size 508.05mm diagonal
Pixel pitch 0.2768mm(H) x 0.2768mm(V)
Video R, G, B Analog lnterface & Digital Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 140MHz
Resolution
Horizontal scan range 30 kHz - 80 kHz
Horizontal scan
Size(Maximum)
442.8mm
Vertical scan range 55 Hz - 75 Hz
Vertical scan
Size(Maximum)
249.075mm
Optimal preset resolution 1600 x 900 (60 Hz)
Highest preset resolution 1600 x 900 (60 Hz) )
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM
Power Source 100-240VAC, 50/60Hz
Power Consumption
2036S Typical < 25W
2036Sa Typical < 32W
Standby < 1 W
Physical
Characteristics
Connector Type 15-pin Mini D-Sub
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base) 378mm
Width 493.8mm
Depth 186mm
Weight (monitor only) 4.2 kg
Weight (with packaging) 5.5kg
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
Altitude:
Operating 0~ 3000m (0~ 10000 ft )
Non-Operating 0~ 5000m (0~ 15000 ft )
