AOC 2036Sa Service Manual

62
CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW
X401 093G 2253B J NXS14.31818AC32F-KAB10
E09513 095G8022 6D504 HARNESS 6P-6P 200MM
A33G0564 2 1L0100 Key-Guide
Q52G 3 75 3M DOUBLE FACE TAPE
GND1 009G6005 1 GROUND TERMINAL
CN602 033G3802 4 BH F CONNECTOR
CN802 033G8021 2E L CONNECTOR 3.5MM 2P
CN801 033G8021 2E L CONNECTOR 3.5MM 2P
040G 45762412B CBPC LABEL
U902 056G 139 3A PC123Y22FZOF SHARP
NR901 061G 5810X RST NTCR 8 OHM +-20% 4A P=7.5mm
C908 063G107K2246S1 X2 CAP 0.22UF K 275VAC
C937 065G 2M103 3B 0.01uF 2KV 20% Y5U
C801 065G 3J1006ET 10PF 5% SL 3KV
C803 065G 3J1006ET 10PF 5% SL 3KV
C902 065G305M1022BP CAP Y2 1000PF M 250VAC
C903 065G305M1022BP CAP Y2 1000PF M 250VAC
C900 065G306M2222BP 2200PF 20%
C925 067G215P1023AV CAP 105C 1000UF M 16V
C918 067G215P1024AV CAP 105C 1000UF M 25V
C920 067G215P1024AV CAP 105C 1000UF M 25V
C811 067G215P4714AV CAP 105C 470UF M 25V
C922 067G215S4713KV
EC 105℃ CAP 470UF M 16V
C604 067G215S4713KV
EC 105℃ CAP 470UF M 16V
C931 067G215S4713KV
EC 105℃ CAP 470UF M 16V
C921 067G215V1023KS EC 1000uF M 16V 12.5*16mm
C907 067G215Z10115A CAP 105C 100UF M 450V
L901 073G 174 65 H2 LINE FILTER 30mH MIN
L906 073G 253191 L CHOKE COIL 1.1uH CC-007802
L907 073G 253191 L CHOKE COIL 1.1uH CC-007802
T801 080GL22T 1 H1 X'FMR INVERTER 72uH
CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND
CN601 088G 30214K DC PHONE JACK 5P GREEN -
D902 093G 60335 DIODE SR515 5A/150V DO-201AD
CN902 095G 825 9T518 HARNESS 9P-9P 120MM
705GQ857021 Q901 ASS'Y
705GQ893027 D906 ASS'Y
PW9A21SHD1SMT POWER BOARD FOR SMT
HS5 Q90G6258 2 HEAT SINK
T901 S80GL17T47V X'FMR POWER 600uH
U601 056G 616 51 IC APA2071JI-TUG 3.1W DIP-16
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
CN511 033G3802 5 BH L CONNECTOR 5PIN
CN512 088G 352 2 XH USB CONN
715G2663 2 USB BOARD PCB
CN501 033G3802 5B Y L CONNECTOR 5P 2.0
CN502 088G 351 2B XH USB CONN
E09508 095G8014 5DH09 HARNESS 5P(PH)-5P(PLUG) 180MM
C410 067G 2151007RT 105C 10UF M 50V
C423 067G 3051014KT EC 100uF 25V PF 6.3x11mm
C421 067G 3051014KT EC 100uF 25V PF 6.3x11mm
C427 067G 3051014KT EC 100uF 25V PF 6.3x11mm
C426 067G 3051014KT EC 100uF 25V PF 6.3x11mm
U401 056G 562560 NO-SUGGEST IC TSUMU18ER-LF LQFP-64 MSTAR
U404 056G 563 52 IC AP1117D33G-13 TO252-3L DIODES
U102 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
U103 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
U402 056G1133129 IC EN25F20-100GCP 2Mb SOP-8
Q409 057G 417 22 T TRA KN2907AS -60V/-0.6A SOT-23
