AOC 2036Sa Service Manual

64
C416 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C407 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C404 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C403 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C103 065G0402220 31 CHIP 22PF 50V NPO
C102 065G0402220 31 CHIP 22PF 50V NPO
C408 065G0402224 17 NO-SUGGEST MLCC 0402 0.22UF Z 16V Y5V
C411 065G0402470 31 MLCC 0402 CAP 47PF J 50V NPO
C412 065G0402470 31 MLCC 0402 CAP 47PF J 50V NPO
C113 065G0402473 12 CHIP 0.047uF 16V X7R
C110 065G0402473 12 CHIP 0.047uF 16V X7R
C109 065G0402473 12 CHIP 0.047uF 16V X7R
C107 065G0402473 12 CHIP 0.047uF 16V X7R
C105 065G0402473 12 CHIP 0.047uF 16V X7R
C101 065G0402473 12 CHIP 0.047uF 16V X7R
C104 065G0402509 31 CHIP 5pF 50V NPO
C108 065G0402509 31 CHIP 5pF 50V NPO
C111 065G0402509 31 CHIP 5pF 50V NPO
FB402 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB401 071G 56V301 B CHIP BEAD 0805 300OHM BULLWILL
FB103 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB101 071G 59K190 B 19 OHM BEAD
ZD103 093G 39GA01 T RLZ5.6B
ZD104 093G 39GA01 T RLZ5.6B
715G3244 1 MAIN BOARD PCB
C433 065G0402105 A5 NO-SUGGEST CAP 0402 1UF K 10V X5R
R482 061G0402000 RST CHIP MAX 0R05 1/16W
R483 061G0402000 RST CHIP MAX 0R05 1/16W
FB405 071G 56G151 A CHIP BEAD 150 OHM
D403 093G 64 42 P BAV70 SOT23 BY PAN JIT
U405 056G1133 34 M24C02-WMN6TP
Q407 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
R485 061G0402000 RST CHIP MAX 0R05 1/16W
R472 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R473 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R474 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R123 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
C434 065G0402224 17 NO-SUGGEST MLCC 0402 0.22UF Z 16V Y5V
R475 061G0402470 RST CHIPR 47 OHM +-5% 1/16W
R476 061G0402470 RST CHIPR 47 OHM +-5% 1/16W
R418 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R419 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R447 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
Q408 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
R448 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
CN001 033G8034 6H H X WAFER 1.0mm SMT 6P
U001 056G 669 10 IC CG7246AM QFN-16(COL)
R012 061G0603000 RST CHIP MAX 0R05 1/10W
R009 061G0603000 RST CHIP MAX 0R05 1/10W
R008 061G0603000 RST CHIP MAX 0R05 1/10W
R001 061G0603000 RST CHIP MAX 0R05 1/10W
R002 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R005 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R006 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R007 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R004 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
C001 065G0603102 31 CHIP 1000PF 50V NPO
