This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this

re. Follow these steps:

1. Remove the base.

2. Follow the manufacturer's instructions to assemble the wall mounting arm.

3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the

the monitor.

4. Insert the 4 screws into the holes and tighten.

5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for

ions on attaching it to the wall.

Noted : VESA mounting screw holes are not available for all models, please check with the dealer or official

ent of AOC.

Distance between the wall-mount holes : 100 x 100 mm

Screw specification for wall-mount : M4 x 10

Adjusting

The recommended resolution for this monitor is 1920 by 1080. To setup the monitor to this resolution, follow the steps below.

For Windows Vista:

1 Click START.

2 Click CONTROL PANEL.

3 Click Appearance and Personalization.

Questions and Answers:

Need help?

Do you have a question about the AOC 2436Swa and is the answer not in the manual?

AOC 2436Swa Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Display diagonal	23.6 \
Viewing angle, vertical	160 °
Contrast ratio (typical)	-
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA)
USB Type-A downstream ports quantity	0
RMS rated power	4 W
Product color	Black
Panel mounting interface	- mm
Power consumption (standby)	1 W
Power consumption (typical)	49 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 5000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 80 %
Operating relative humidity (H-H)	10 - 85 %
