AOC 24G4X User Manual

5
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY
and contact a Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.
The power cords shall be safety approved. For Germany, it shall be H03VV-F, 3G, 0.75 mm
2
, or better.
For other countries, the suitable types shall be used accordingly.
Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the
equalizer to maximum increases the earphones and headphones output voltage and therefore the sound
pressure level.

AOC 24G4X Specifications

General

Warranty period	3 year(s)
DDC/CI	Yes
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Response time	0.5 ms
Display diagonal	23.8 \
Display technology	LCD
Native aspect ratio	-
Vertical scan range	48 - 180 Hz
Maximum refresh rate	180 Hz
Horizontal scan range	30 - 200 kHz
Viewable size, vertical	296.46 mm
Display number of colors	16.7 million colors
Display diagonal (metric)	60.5 cm
Viewable size, horizontal	527.04 mm
High Dynamic Range (HDR) technology	DisplayHDR 400, High Dynamic Range 10 (HDR10)
Pivot angle	-91 - 91 °
Tilt angle range	-5 - 23 °
Input current	1.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Power consumption (max)	37 W
Power consumption (standby)	0.3 W
Power consumption (typical)	21 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Feet color	Black
Market positioning	Gaming
Cables included	AC
Package type	Box
