2. LCD Monitor Description
The LCD Monitor will contain main board, power board, key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Video signal, DDC
Power Board
(Include adapter and inverter)
Flat Panel and
CCFL backlight
Main Board
RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
100V~240V
Monitor Block Diagram
Key board

AOC 519Sw Specifications

General

Brand	AOC
Model	519Sw
Category	Monitor
Language	English
