AOC E2236VWA Service Manual

21.5" LCD Color Monitor AOC e2236Vwa
59
13. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp for the latest information.
TI9AA8NB6WA2PNE
Location
Part No. Description Remark
040G 58162435A P/N LABEL FOR MANUAL PE BAG
050G 600 1 W WHITE STRAP (1G004991)
052G 1186 SMALL TAPE
052G 1208 A ALUMINIUM TAPE
052G 1211 B Conductive Tape 85mm *40mm *0.09mm
052G 2191 A PAPER TAPE
E07801 078G0020E03 V SPK 4OHM 2W (430+230)MM 40*20MM
E08904 089G 173 56 4B AUDIO CABLE
E08905 089G 175 8 C USB CABLE A+B 1.8M
E08902 089G 715HAAE01 SIGNAL CABLE
E08901 089G404A15N IS POWER CORD
E09504 095G176J 10E01 FFC CABLE 10PIN P0.5MM 565MM
E09514 095G176J 10E02 FFC CABLE 10PIN P0.5MM 370MM
E09508 095G8014 5XH09 HARNESS 5P(PLUG)-5P(2501) 200MM
E09503 095G8014 7T588 HARNESS 7P(PLUG)-6P(C2003) 260MM
0D1G1730 8120 SCREW
0M1G 130 6120 SCREW M3X6
705GH934025 21.5"LCD STAND-BASE ASS'Y
E750 750GLU215H1614N000 PANEL M215HW01 V600 SH AUO
E750 750GLU215H1624N000 PANEL M215HW01 V60A SH AUO 2nd source
A15G0647F02 Main Frame-e2236
A34G1160AEDC2B0130 BEZEL e2236
A34G1161AEDABS0100 REAR COVER21.5"
A85G0140301MCM AC Shield
ADPC91503HD3 ADAPTER BOARD
H12G6200 10 RUBBER PAD
H26G 800504 2A barcode
H40G 22N61540A ID LABEL
H40G 58161569A USB LABEL
H40G 58261537A e936Vw POP LABEL
H40G 58261538A Win7 GOLD EPA LABEL
H40G 58261567A CARTON LABEL
H41G780961517A QSG
H44GB005101 EPS
H44GB005201 EPS
H44GB005615 7B CARTON
H45G 77 6 PE PACKING
H45G 87 18 12 EPE_COVER_MONITOR
H70G200961543A CD MANUAL
KEPC9HAB KEY BOARD
LNPC9B362AHD1 CONVERTER BOARD
Q12G6600 6 FOOT
Q45G 76 28 H A PE BAG FOR MANUAL
Q45G 76 28V13 A PE BAG
Q50G 4 10 TIE (Y1900221)
