AOC E2236VWA Service Manual

21.5" LCD Color Monitor AOC e2236Vwa
61
CN102 088G 35424F D DVI 24PIN CONN F ATTACHED SCREW
X401 093G 2253B J NXS14.31818AC32F-KAB10
E09513 095G8022 6X504 HARNESS 6P-6P 200MM
A33G0564 2 1L0100 Key-Guide
Q52G 3 75 3M DOUBLE FACE TAPE
040G 45762412B CBPC LABEL
C802 067G 4151017KV EC 100uF 50V ED 8*12
C804 067G 415479 9K EC 4.7UF 20% 100V ED 8*12
LN9B362AHD1SMT CONVERTER BOARD FOR SMT
CN511 033G3802 5 BH L CONNECTOR 5PIN
CN512 088G 352 2 XH USB CONN
715G2663 2 USB BOARD PCB
CN501 033G3802 5B Y L CONN 2.0 5P
CN502 088G 351 2B XH USB CONN
IC901 056G 581 20 IC TOP255EN eSIP-7C
0M1G 930 8120 SCREW
Q11G0026 1 cable clip
HS1 Q90G6263 6 HEAT SINK
Q608 057G 417 18 T PMBT3904 SOT-23
Q607 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
R623 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R628 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R917 061G06031001FT RST CHIP 1K 1/10W 1%
R913 061G06031002FT RST CHIP 10K 1/10W 1%
R601 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R603 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R609 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R610 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R613 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R614 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA
R602 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R604 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R605 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R912 061G0603103 JW RST CHIP 10K 1/10W 5% WALSIN
R606 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA
R607 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA
R916 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN
R615 061G0603472 JF RST CHIPR 4.7KOHM +-5% 1/10W FENGHUA
R611 061G0603563 JF RST CHIPR 56KOHM 5% 1/10W FENGHUA
R612 061G0603751 JF RST CHIPR 750OHM +- 5% 1/10W FENGHUA
R915 061G06039311FT RST CHIPR 9.31k 1% 1/10W
R608 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R923 061G0805103 JT RST CHIPR 10K OHM +- 5% 1/8W TZAI YUAN
R903 061G08051102FT RST CHIP 11K 1/8W 1%
R924 061G0805689 JT RST CHIPR 6.8R +-5% 1/8W TZAI YUAN
R925 061G08058202FT RST CHIPR 82K +-1% 1/8W TZAI YUAN
RJ601 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
F601 061G12060004JT RST CHIP MAX 0R05 1/4W TZAI YUAN
R927 061G12060004JT RST CHIP MAX 0R05 1/4W TZAI YUAN
R910 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R926 061G1206229 JT RST CHIPR 2R2 +-5% 1/4W TZAI YUAN
