AOC E2236VWA - Electrical Block Diagram

21.5" LCD Color Monitor AOC e2236Vwa
21
6.2 Electrical Block Diagram
6.2.1 Scalar Board
715G3329 1 2
715G2883 1 6
FLASH MEMORY
MX25L2026MI
(U402)
Scalar TSUMU58EHL-LF-1
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(
CN301
)
D-Sub
Connector
(
CN101
)
Crystal 14.31818MHz
(X401)
Key Control
Interface
(CN402)
EEPROM
AT24C02BN
(
U101
)
DDC1_SDA
DDC1_SCL
EEPROM
AT24C02BN
(
U102
)
DDC2_SDA
DDC2_SCL
FLASH MEMORY
SST25LF020A
(U402)
Scalar TSUMU58EHL-LF-1
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(
CN301
)
D-Sub
Connector
(
CN101
)
Crystal 14.31818MHz
(X401)
Key Control
Interface
(CN402)
EEPROM
M24C02
(
U101
)
DDC1_SDA
DDC1_SCL
DVI
Connector
(
CN102
)
EEPROM
M24C02
(
U102
)
DDC2_SDA
DDC2_SCL
EEPROM
M24C02
(
U403
)
DVI
Connector
(
CN102
)
