AOC e2260Sd User Manual

54
Panel
Model name
E2060SWN/E2060SWDN/E2060SWDAN
/E2060SWDA/ E2060PWDA
/E2060SW/E2060SWD /E2060SWDU
Driving system
TFT Color LCD
Viewable Image Size
49.5cm diagonal
Pixel pitch
0.27mm(H)X0.27mm(V)
Video
(E2060SWDU/E2060SWDN/E2060SWDAN
/E2060SWDA/ E2060PWDA/E2060SWD)
R, G, B Analog lnterface & Digital Interface
Video (E2060SW E2060SWN)
R, G, B Analog lnterface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
108MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan Size(Maximum)
432mm
Vertical scan range
50 Hz - 76 Hz
Vertical scan Size(Maximum)
239.76mm
Optimal preset resolution
1600×900@60Hz
Plug & Play
VESA DDC2B/CI
Input Connector
(E2060SWDU/E2060SWDN/E2060SWDAN
/E2060SWDA/ E2060PWDA/E2060SWD)
D-Sub 15pin; DVI 24pin
Input Connector (E2060SW
E2060SWN)
D-Sub 15pin;
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
100-240V~, 50/60Hz
Power Consumption
Active: 23 W (typical)
35 W (typical)（E2060SWDU）
Standby < 0.5 W
Standby < 1 W（E2060SWDU）
Off timer
0-24 hrs
Speakers(E2060SWDU/E2060SWDA/
E2060PWDA /E2060SWDAN)
2WX2
Physical Characteristics
Connector Type
(E2060SWDU/E2060SWDN/E2060SWDAN
/E2060SWDA/ E2060PWDA/E2060SWD)
15-pin Mini D-Sub DVI-D
Connector Type (E2060SW
/E2060SWN)
15-pin Mini D-Sub
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25° to 55°
Humidity:
