AOC e2260Sd User Manual

55
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Panel
Model name
E2260PHU/E2260SHU/E2260PDA/E2260SDA/E2260SD/E2260PQ
Driving system
TFT Color LCD
Viewable Image Size
55.86 cm diagonal
Pixel pitch
0.282mm(H) x 0.282mm(V)
Video (E2260PQ)
R, G, B Analog lnterface & Digital Interface & DP lnterface
Video (E2260PHU/E2260SHU)
R, G, B Analog lnterface & Digital Interface & HDMI lnterface
Video
(E2260PDA/E2260SDA/E2260SD)
R, G, B Analog lnterface & Digital Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
146 MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan Size(Maximum)
473.76mm
Vertical scan range
50Hz - 76 Hz
Vertical scan Size(Maximum)
296.1mm
Optimal preset resolution
1680 x 1050@60Hz
Plug & Play
VESA DDC2B/CI
Input connector (E2260PQ)
D-Sub 15pin DVI 24pin，DP
Input connector
(E2260PHU/E2260SHU)
D-Sub 15pin DVI 24pin，HDMI
Input connector
(E2260PDA/E2260SDA/E2260SD)
D-Sub 15pin DVI 24pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
100-240V~, 50/60Hz
Power Consumption
Active: 38W(typical)
Standby < 0.5 W
Off timer
0-24 hrs
Speakers(E2260PDA/E2260SDA
E2260PHU/E2260SHU/E2260PQ)
2W x 2
Physical
Characteristics
Connector type
(E2260PHU/E2260SHU)
15-pin Mini D-Sub DVI-D,HDMI
Connector type (E2260PQ)
15-pin Mini D-Sub DVI-D,DP
Connector type
(E2260PDA/E2260SDA/E2260SD)
15-pin Mini D-Sub DVI-D
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25°to 55°
