AOC e2260Swdn Service Manual

24
4. Input/Output Specification
4.1 D-SUB connectors and DVI connectors
Pin Assignments
Pin Number
15-Pin Side of the Signal Cable
Pin Number 15-Pin Side of the Signal Cable
1
Video-Red
9 +5V
2
Video-Green
10
Ground
3
Video-Blue
11 N.C.
4 N.C. 12 DDC- Serial data
5
Detect Cable
13 H-
sync
6 GND-R 14 V- sync
7 GND-G 15 DDC- Serial clock
8 GND-B
Pin Number 24-Pin Color Display Signal Cable Pin Number 24-Pin Color Display Signal Cable
1
TMDS
data 2－
13
TMDS
data 3＋
2
TMDS
data 2＋
14
＋5V Power
3 TMDS data 2/4 Shield 15
Ground（对于 +5V ）
4
TMDS
data 4－
16
Hot Plug Detect
5
TMDS
data 4＋
17
TMDS data 0－
6 DDC Clock 18
TMDS
data 0＋
7 DDC data 19 TMDS data 0/5 Shield
8 N.C. 20
TMDS
data 5－
9
TMDS
data 1－
21
TMDS data 5＋
10
TMDS
data 1＋
22 TMDS
Clock Shield
11 TMDS data 1/3 Shield 23 TMDS Clock +
12
TMDS
data 3－
24
TMDS Clock－

AOC e2260Swdn Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Touch Screen	no
Webcam	no
OS Compatibility	windows
Screen Size	21.5 inches
Aspect Ratio	16:9
Resolution	1920 x 1080
Refresh Rate	60hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	60 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
Built-In Speakers	no
Headphones Output	no
Power Consumption	30 watts
Width with Stand	20.1 inches
Net Weight without Stand	5.9 pounds
