AOC e2260Swdn Service Manual

4
1. Monitor Specifications
Panel
Model number E2260SWDN
Driving system TFT Color LCD
Viewable Image Size 54.7 cm diagonal
Pixel pitch 0.0827*RGB (H) mm x 0.248 (V) mm
Video R, G, B Analog lnterface & Digital Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 144 MHz
Resolution
Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum) 476.64mm
Vertical scan range 50 Hz - 76 Hz
Vertical scan Size(Maximum) 268.11mm
Optimal preset resolution 1920×1080@60Hz
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin.DVI-D.
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source 100~240VAC, 50/60Hz
Power Consumption
Active < 26W(typical)
Standby < 0.5 W
Off timer 0-24 hrs
Speakers
Physical
Characteristics
Connector Type 15-pin Mini D-Sub.DVI-D
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base) 373mm
Width 511mm
Depth 185 mm
Weight (monitor only) 2.676 kg
Environmental
Temperature:
Operating 0°Cto 40° C
Non-Operating -25°Cto 55°C
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
Altitude:
Operating 0~ 3,658m (0~ 12,000 ft )
Non-Operating 0~ 12,192m (0~ 40,000 ft )

AOC e2260Swdn Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Touch Screen	no
Webcam	no
OS Compatibility	windows
Screen Size	21.5 inches
Aspect Ratio	16:9
Resolution	1920 x 1080
Refresh Rate	60hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	60 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
Built-In Speakers	no
Headphones Output	no
Power Consumption	30 watts
Width with Stand	20.1 inches
Net Weight without Stand	5.9 pounds
