AOC e2260Swdn Service Manual

27
4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz) - 1000 1300 mA 1,5
I
LCD-BLACK
(60Hz) - 1300 1690 mA 2,5
I
LCD-BLACK
(75Hz) - 2000 mA 5
Power Consumption P
LCD
- 5.00 6.5 Watt 1
Inrush current I
RUSH
- - 3.0 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 110 120 mA 2,7
LED String Voltage Vs 48.0 51.2 54.4 V 3,7
Power Consumption PBar - 11.3 12.0 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7

AOC e2260Swdn Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Touch Screen	no
Webcam	no
OS Compatibility	windows
Screen Size	21.5 inches
Aspect Ratio	16:9
Resolution	1920 x 1080
Refresh Rate	60hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	60 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
Built-In Speakers	no
Headphones Output	no
Power Consumption	30 watts
Width with Stand	20.1 inches
Net Weight without Stand	5.9 pounds
