AOC e2350Sd Servise Manual

84
LNPCAC581GHD1 CONVERTER G4013-P01-002-X-3-101201
BD901 093G 50460515 BRIDGE KBP308G-C 3A 800V KBP
CN402 033G3802 6B Y L WAFER
CN701 033G3802 9B Y L CONN 2.0 9P
CN408 033G801930F CH L FFC CONNECTOR 30P 1.0pitch
040G 45762412B CBPC LABEL
R707 061G152M47964L SY RST MOFR 4.7 OHM +-5% 2WS FUTABA
CN101 088G 35315FVXH D-SUB CONN V/T 15P BLUE 1*1 V/T 30.8
CN102 088G 35424FVXH DVI CONN V/T 24P WHITE
X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10
709G4502 HM001 COMSUPTIVE ASS'Y
AIGAN2A1H1 MAIN BOARD FOR AI
LED001 081G 12 1F GP
LED Φ3mm 黄绿双色 GP32032M/G307-ZY-50-C
CN001 095G820H 6TE10 HARNESS 6P(SANW)-6P(2008) 120
CN001 095G820H 6WE10 HARNESS 6P(SANW)-6P(2008) 120 2nd source
709G4747 HM001 COMSUPTIVE ASS'Y
SMTKEPCAHB5 KEY BOARD FOR SMT
Q901 057G 667941 MOSFET P0765ATF 7 650 TO-220F
HS1 090G6064 1 HEAT SINK
0M1G 930 8120 SCREW 3x8
HS3 090G6084 1 GP HEAT SINK
D906 093G 60507 SCHOTTKY SRF1060 C0 10A 60V ITO-220AB
0M1G 930 8120 SCREW 3x8
055G 23524 WELDING FLUX WITHOUT PB
Q51G 6 4509 GLUE_RTV
Q55G 100625 TIN STICK_LOW ARGENTUM
U901 056G 379529 AC/DC CONVERTER IC LD7576AGR SOP-7
RJ801 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R916 061G08051002FT RST CHIP 10K 1/8W 1%
R907 061G0805102 JT RST CHIPR 1K OHM +- 5% 1/8W TZAI YUAN
R928 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R918 061G0805103 JT RST 0805 10K 5% 1/8W
R920 061G0805202 JF RST CHIPR 2KOHM +-5% 1/8W FENGHUA
R919 061G0805221 JF RST CHIPR 220 OHM +-5% 1/8W FENGHUA
R905 061G0805471 JT RST CHIPR 470OHM +-5% 1/8W TZAI YUAN
R925 061G08059101FF RST CHIPR 9.1KOHM +-1% 1/8W FENGHUA
F801 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
R917 061G1206100 JT RST CHIPR 10 OHM +-5% 1/4W TZAI YUAN
R903 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R909 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R910 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R912 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R929 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R930 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R911 061G1206103 JF RST CHIPR 10KOHM +-5% 1/4W FENGHUA
R908 061G1206103 JT RST CHIPR 10KOHM +-5% 1/4W TZAI YUAN
R913 061G1206109 JT RST CHIPR 1 OHM +-5% 1/4W TZAI YUAN
R923 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN
R900 061G1206624 JF RST CHIPR 620KOHM +-5% 1/4W FENGHUA
R901 061G1206624 JF RST CHIPR 620KOHM +-5% 1/4W FENGHUA
R902 061G1206624 JF RST CHIPR 620KOHM +-5% 1/4W FENGHUA
C923 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C906 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C914 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C915 065G080510332K Y CAP CHIP 0805 10N 50V X7R +/-10%
