14
Warm
6500K
Recall Warm Color Temperature from EEPROM.
Normal
7300K
Recall Normal Color Temperature from EEPROM.
Cool
9300K
Recall Cool Color Temperature from EE
PROM.
sRGB
Recall SRGB Color Temperature from E
EPROM.
User
Red
Red Gain from Digital-register
Green Green
Gain
Digital-register.
Blue
Blue Gain from Digital-register
13
15
Table of Contents
Description Table of Contents
1
Table of Contents
1
Revision List
2
Important Safety Notice
3
1 Monitor Specification
4
2 LCD Monitor Description
5
3 Operation Instruction
6
General Instructions
6
Control Buttons and Connections
6
OSD Menu
8
4 Input/Output Specification
25
Input Signal Connector
25
Factory Preset Display Modes
26
Panel Specification
27
5 Block Diagram
30
Main Board
30
Power Board
31
6 Schematic
32
Main Board
32
Power Board
37
Light Sensor Borad
39
Key Board
40
7 PCB Layout
41
Main Board
41
Power Board
42
Light Sensor Borad
44
Key Board
45
8 Maintainability
46
Equipments and Tools Requirement
46
Trouble Shooting
47
9 FOS Testing
51
10 Firmware and DDC Instruction
55
DDC Instruction
66
11 White-Balance,Luminance Adjustment
73
12 Monitor Exploded View
75
13 BOM List
76
5
Based on 1 rating
