AOC e2440Va User Manual

76
13. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp
for the latest information.
TKAANT2BWWA1DNE
Location Part No. Description Remark
040G 58162435A P/N LABEL FOR MANUAL PE BAG
050G 600 1 W WHITE STRAP (1G004991)
052G 1150 C INSULATING TAPE
052G 1207 A Conductive Tape 45mm *25mm *0.08mm
052G 1211 B Conductive Tape 85mm *40mm *0.09mm
HDCP-L 070GHDCP500HDC NO-SUGGEST HDCP CODE
E07801 078G025A 2 Y SPK 4 OHM 2.5 W 340/150mm 42.2X22.2mm
E08904 089G 17356H580 AUDIO CABLE 1.8M without PE bag
E08902 089G 715HAAE01 SIGNAL CABLE
E08901 089G404A15N IS POWER CORD
E09504 095G176W 10E07 FFC CABLE 10PIN P0.5MM 370MM
E09514 095G176W 10E08 FFC CABLE 10PIN P0.5MM 325MM
E09501 095G8018 3TE39 HARNESS 30P-30P 410MM
E09503 095G8022 5TE01 HARNESS 5P(A1253)-5P(A1253) 260MM
E09502 095G8022 7TE01 HARNESS 7P-6P 130MM
E09505 095G802210TE01 HARNESS 10P(A1253)-10P(A1253) 90MM
0D1G1030 8120 screw
705GHA34030 2440 BASE ASS'Y
705GHA34032 E2440VA REAR COVER_STAND ASS'Y
E750 750GLU240H1623N000 PANEL M240HW01 V60A XM AUO
A34G1863DAVB1M0130 BEZEL
E080 ADPCA1236HD1 ADAPTER BOARD
H01G6009 1 Screw
H15G0035401201 MAIN FRAME FOR 2440
H26G 800504 2A barcode
H33G0022 1 1L LENS_AOC_L201WA-2040LED
H33G0023AED 1B KEY PAD_AOC_L201WA-2040LED
H40G 24N61528B e2440Va EU ID LABEL
H40G 58361511A e2040v POP LABEL
H40G 58361511A esensor LABEL
H40G 58361538A e2440Va CAROTN LABEL
H40G 58361568A SRS WIN7 SIL EPA LABEL
H41G780961525A QSG
H44GD005101 PULP
H44GD005201 PULP
H44GD005615 2A 2440Va CARTON
H45G 77 6 PE PACKING
H45G 87 1 20 EPE COVER
H45G 87 1810H A EPE COVER FOR BASE
H52G6025 16 58 mylar
H70G201061517B e2440Va CD MANUAL
KEPC9HC2 KEY BOARD
LNPCAK372AHD1 CONVERTER BOARD
LSPC9HC2 LIGHT SENSOR BOARD
Q45G 76 28 H A PE BAG FOR MANUAL
Q52G 1185 99 big carton tape for aoc
Q52G6019 14 TAPE
0Q1G 130 8120 SCREW 42A9930011
