AOC e2450Swd Service Manual

Service Manual e2450Swd
37
C718
100N 16V
Audio_DET1
R727
NC/0 OHM +-5% 1/8W
C704
100N 16V
Q706
LMBT3904LT1G
on_BACKLIGHT 5
R714
10K 1/16W 5%
R712 NC/100R 1/16W 5%
U703
AZ1117H-1.8-E1
3 2
1 4
VI VO
GND 4
R722
NC/10K 1/16W 5%
R701
22K 1/16W 5%
+5V
C703
100N 16V
TO-252
VCC3.3
R702
4K7 1/16W 5%
R704
10K 1/16W 5%
R711 NC/0R05 1/16W
R703 100R 1/16W 5%
+
C716
100uF16V
TO252
R718
NC
ON/OFF
Audio_DET2
U702
NC/G1117-33T43UF
1 2 3
ADJ(GND) VOUT(TAB) VIN
R723
NC/4K7 1/16W 5%
R721
4K7 1/16W 5%
DUAL 1.0
e2252Vw
B
7 7Friday , March 11, 2011
715G4502-M01-000-0040
<称爹>
POWER
G4502-M01-000-0040-2-110311
<Variant Name>
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
DIM
Q707
NC/2N3904S-RTK/PS
VCC3.3
DIM
VCC3.3
VCC3.3
R798
NC/100R 1/16W 5%
C709
NC/100NF 25V
C715
220N16V
U701 AZ1117H-3.3TRG1
3
1
2
4
INPUT
ADJ/GND
OUTPUT
4
C706
100N 16V
R716
NC/10K 1/16W 5%
VLCD 6
R720
NC
U401=NT68660FG U703 U704 R707 C710 C712 C713 is NC
R707
4.7 OHM +-5% 2WS
R710
NC/100K 1/16W 5%
Adj_BACKLIGHT 5
Audio_DET 5
VCC3.3
ON/OFF
C707
NC/100N 16V
R708
NC/10K 1/16W 5%
+
C702
100uF16V
+
C710
100uF16V
With audio Add R711 = 0 ohm, R712 / R798 = 100 ohm
R706
NC/10K 1/16W 5%
+5V
R709
NC/22K 1/16W 5%
C708
NC
U704
3 2
1
VIN VOUT
GND
PS_EN 5
C701
100N 16V
C714
NC/100NF 25V
VCC3.3 5
R713 NC
C713
100N 16V
+5V 3,4,5
+5V
CN701
CONN
1
2
3
4
5
6
7
8
9
R725
NC
Audio_EN 5
R717
NC
R715
100K 1/16W 5%
Q702
NC/2N3904S-RTK/PS
R719
22K 1/16W 5%
+5V3,4,5
Q701
LMBT3904LT1G
VCC1.8 5
Panel_ON5
Audio_EN1
R726
0 OHM +-5% 1/8W
CN702
NC/CONN
1
2
3
4
5
6
Q704
NC/AO4449 -7A/-30V
1 2 3 4
8 7 6 5
S S S G
D D D D
+5V
R724
NC
+5V
+
C705
100uF16V
C712
100N 16V
Q705
AO3401A
R799
10K 1/16W 5%
Q703
NC/2N3904S-RTK/PS
VCC3.3
VCC1.8
VLCD
C717
NC/100NF 25V
+5V
FB701
0 OHM +-5% 1/8W

AOC e2450Swd Specifications

General

3D	No
Pixel pitch	0.2715 x 0.2715 mm
Aspect ratio	16:9
Display diagonal	23.6 \
Viewable size diagonal	598 mm
Viewable size, vertical	293.22 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	521.28 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Placement supported	Horizontal
Screen saving functions	Yes
Number of products included	1 pc(s)
DVI-I ports quantity	-
USB Type-A downstream ports quantity	0
Certification	CE, cCSAus, FCC, CCC, RoHs, EPA 5.0, Windows Vista/Win7, china RoHs
Product color	Black
LED indicators	Power
Tilt angle range	-4 - 17 °
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Package depth	113 mm
Package width	625 mm
Package height	437 mm
Package weight	7300 g

Weight and Dimensions

Depth (with stand)	205.1 mm
Width (with stand)	569.7 mm
Height (with stand)	413.9 mm
Weight (with stand)	4450 g
Width (without stand)	- mm
Weight (without stand)	- g
