AOC e2450Swd Service Manual

Service Manual e2450Swd
4
1. Monitor Specifications
1.1 Product Features
Panel
Model number
e2450Swd
Driving system
TFT Color LCD
Viewable Image Size
59.8cm diagonal
Pixel pitch
0.2715mm(H) x 0.2715mm(V)
Video
R, G, B Analog Interface & Digital Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
148.5MHz
Resolution
Horizontal scan range
30 kHz – 83 kHz
Horizontal scan Size(Maximum)
521.28mm
Vertical scan range
55 Hz - 75 Hz
Vertical scan Size(Maximum)
293.22mm
Optimal preset resolution
1920 x 1080 (60 Hz)
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15pin,DVI-24pin
Input Video Signal
Analog: 0.7Vp-p(standard),75 OHM, Positive& DVI-D
Digital Interface (TMDS)
Power Source
100-240V~ , 50/60Hz
Power Consumption
Active < 30W(typical)
Standby < 0.5 W
Off timer
00-24 hrs
Physical
Characteristics
Connector Type
15-pin Mini D-Sub & 24-pin DVI
Signal Cable Type
Detachable
Dimensions & Weight:
Height (with base)
413.95mm
Width
569.22mm
Depth
205mm
Weight (monitor only)
4.202kg
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25° to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )

AOC e2450Swd Specifications

General

3D	No
Pixel pitch	0.2715 x 0.2715 mm
Aspect ratio	16:9
Display diagonal	23.6 \
Viewable size diagonal	598 mm
Viewable size, vertical	293.22 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	521.28 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Placement supported	Horizontal
Screen saving functions	Yes
Number of products included	1 pc(s)
DVI-I ports quantity	-
USB Type-A downstream ports quantity	0
Certification	CE, cCSAus, FCC, CCC, RoHs, EPA 5.0, Windows Vista/Win7, china RoHs
Product color	Black
LED indicators	Power
Tilt angle range	-4 - 17 °
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Package depth	113 mm
Package width	625 mm
Package height	437 mm
Package weight	7300 g

Weight and Dimensions

Depth (with stand)	205.1 mm
Width (with stand)	569.7 mm
Height (with stand)	413.9 mm
Weight (with stand)	4450 g
Width (without stand)	- mm
Weight (without stand)	- g
