Service Manual e2450Swd
65
J812
095G 90 23
JUMP WIRE - -
1
J809
095G 90 23
JUMP WIRE - -
1
J909
095G 90 23
JUMP WIRE - -
1
J811
095G 90 23
JUMP WIRE - -
1
J805
095G 90 23
JUMP WIRE - -
1
J802
095G 90 23
JUMP WIRE - -
1
J907
095G 90 23
JUMP WIRE - -
1
C801
367G215X3314AT
EC 330UF 20% 25V 10*12 RF
1
C913
367G215X4707AT
EC 47uF 20% 50V - 6.3*11mm RG
1
C922
367G415X4713AT
EC 470uf 20% 16V 10X13 RS
1
C918
367G415X6814AT
EC 680uf 20% 25V 10x20 RS
1
E715
715G4744P02000001C
PWR PCB FR1 SS 193X132+1.6(mm)
1
E715
715G4744P02000001M
PWR PCB FR1 SS 195*132*1.6MM
1
Q51G 6 4509
GLUE_RTV
1
T901
S80GL22T3V3
X'FMR 490UH 7% 4UH P-C28-144
1
Q12G6600 6
FOOT
4
Q33G0504ABJ 1B0100
STAND_TOP
1
Q33G0505ABJ 1L0100
COVER_HINGE
1
Q34G7395ABJ 1B0100
STAND
1
Q34G7396AED01B0100
BASE
1
Q40G000162471A
CARTON LABEL+BARCODE FOR 1
1.02
Q52G6025 13155
INSULATING SHEET
1
E09501
S95G179T30PE38
FFC CABLE 30P 215mm 1.0MM
1
