AOC E2460SD User Manual

19
Hotkeys
1
Source/Auto/Exit
2
Eco (DCR)
3
4:3 or Wide/+
4
Menu/Enter
5
Power
Power
Press the Power button to turn on/off the monitor.
Menu/Enter
Press to display the OSD or confirm the selection.
Eco (DCR)
Press the Eco key continuously to select the Eco mode of brightness and DCR on when there is no OSD. (Eco
mode hot key may not be available in all models).
4:3 or Wide
When there is no OSD, press + continuously to change 4:3 or wide image ratio. (If the product screen size is 4:3 or
input signal resolution is wide format, the hot key is disable to adjust. )
Auto / Exit
When the OSD is closed, press Auto/Source/Exit button continuously about 2 second to do auto configure (only for
the models with dual or more inputs). When the OSD is closed, press Auto/Source/Exit button will be Source hot
key function (Only for the models with dual or more inputs).

AOC E2460SD Specifications

General

3D	No
Panel type	TN
Pixel pitch	276 x 276 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	165 MHz
Display diagonal	24 \
Display technology	LCD
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	298.89 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	531.36 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	55 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI ports quantity	0
Tilt angle range	-5 - 20 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.13 W
Power consumption (standby)	0.29 W
Power consumption (typical)	18.54 W
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	-
Package type	Box
Package depth	131 mm
Package width	621 mm
Package height	476 mm
Package weight	6100 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	AC, VGA

Weight and Dimensions

Depth (with stand)	219.3 mm
Height (with stand)	403.05 mm
Weight (with stand)	4640 g
Depth (without stand)	52.95 mm
Width (without stand)	565.4 mm
Height (without stand)	342.9 mm
Weight (without stand)	4440 g
