AOC e960Swn - Page 25

25
4.3.3 Electrical Characteristics
Ta = 25°C
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz) - 720 940 mA 1
I
LCD-BLACK
(60Hz) - 900 1200 mA 2
I
LCD-BLACK
(75Hz) - 1380 mA
Power Consumption P
LCD
- 3.60 4.7 Watt 1
Inrush current I
RUSH
- - 3.0 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 60 65 mA 2,7
LED String Voltage Vs - 51.2 56 V 3,7
Power Consumption PBar - 9.2 10.1 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7
