4.3.4 Optical Characteristics
Ta= 25°C, V
LCD
=5.0V, fv=60Hz, D
CLK
= 77.0MHz, Is=60mA
Parameter Symbol
Values
Units Notes
Min Typ Max
Contrast Ratio CR 400 600 -
1
(PR-880)
Surface Luminance, white L
WH
160 200 - cd/m
2
2
(PR-880)
Luminance Variation

WHITE
9P 75 - - %
3
(PR-880)
Response Time
Rise Time Tr
R
- 1.1 2.6 ms
4
(RD80S)
Decay Time Tr
D
- 3.9 7.4 ms
Color Coordinates
[CIE1931]
RED
Rx
Typ
-0.03
0.627
Typ
+0.03
(PR-650)
Ry 0.347
GREEN
Gx 0.339
Gy 0.621
BLUE
Bx 0.154
By 0.050
WHITE
Wx 0.313
Wy 0.329
Viewing Angle (CR>5)
5
(PR-880)
x axis, right(=0°) r
45 50 Degree
x axis, left (=180°) l
45 50
y axis, up (=90°) u
20 25
y axis, down (=270°) d
40 45
Viewing Angle (CR>10)
x axis, right(=0°) r
40 45 Degree
x axis, left (=180°) l
40 45
y axis, up (=90°) u
10 15
y axis, down (=270°) d
30 35
Crosstalk 1.5 %
6
(PR880)

AOC e960Swn Specifications

General

Aspect ratio	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	30 - 60 kHz
Display brightness (typical)	200 cd/m²
Display viewable area (HxV)	409.8 x 230.4 mm
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	TCO 5.2, CE/CB, cTUVus, FCC, CCC, EPA 5.2, CH RoHS, CEL 1
Product color	Black
Compliance industry standards	DDC2B, DDC2B/CI
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package depth	114 mm
Package width	493 mm
Package height	422 mm
Package weight	3200 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	440 mm
Height (without stand)	346 mm
Weight (without stand)	2080 g
