AOC e960Swn User Manual

52
6308L-1839A
LTXXNSSXX1-01850B20, 422.6*238.1, LGC, T,
X, X, N, S, S, N, X, X, 1, 01850, BOTTOM, 20
6871L-2339C
Source, Single, None-C/SKD,
LM185WH2-TJBA-T11, Single Side
C66 0CH2103K562 10NF, K, 50V, X7R, 0.9mm, 1608, R/TP
C61,C8,C86,C9 0CH2104K562 0.1UF 50V K X7R 1608 R/TP
C63,C64,C65 0CH2473H562 47nF, K, 25V, X7R, 0.9mm, 1608, R/TP
C10,C3,C5,C6,C7,C90 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C70,C71 0CH2A-0010A 33nF, M, 25V, X7R, 0.9mm, 1608, R/TP
C73 0CH2A-0011A
10U F, 16 Volt, K PER, X5R(JB), 3216 R/TP,
T=0.95(MAX)
C1,C135,C137,C139,C
41,C42,C43,C44,C45,
C46,C47,C48,C49,C50
,C51,C52,C53,C54,C8
4,C92,C98
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C87 0CH2A-0017A
2.2U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C151,C152,C153,C68,
C69,C80,C81,C83
0CH2A-0026A
10U F, 25 Volt, K PER, X5R(JB), 3225 R/TP,
T=1.0(MAX)
C62 0CH2A-0034A
10U F, 25 Volt, K PER, X5R(JB), 3216 R/TP,
T1.0(MAX)
C89 0CH5471K412 470PF, J, 50V, 1608, R/TP, 0.9mm
D1,D2,D3 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0061A SDZ6V2D, AUK, SOD-323, R/TP
D4 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FFST-0003A
Fast Blow Fuse ** F0603FA2000V032TM, AEM,
Ceramic, 32V, 2A, UL/CSA, 1.6X0.8X0.8, R/TP
U2 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K, 5ms,
TSSOP, R/TP, 8
US1 0ISML-0006A
SM4023, SILICONMITUS, NOTEBOOK, 8CH
L/S+BOOST+OP-AMP+D/C+LDO+PVCOM+GPM
, 6*6 QFN, R/TP, 48
UC1 0ITLL-0042A
TL2335ML, TLI, LVDS, 6/8, 1, MINI-LVDS, 6,
1-3PAIR, DRD, GIP, AFRC, DGA, QUARK, MLF,
TR, 56
L1 0LCAA-0069B
TNI8016-100M, DACOWELL, 10UH, M=20%,
2.1A, 0.093, 8.0X11.0X1.8 (1.2MM, IN-BOARD),
R/TP

AOC e960Swn Specifications

General

Aspect ratio	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	30 - 60 kHz
Display brightness (typical)	200 cd/m²
Display viewable area (HxV)	409.8 x 230.4 mm
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	TCO 5.2, CE/CB, cTUVus, FCC, CCC, EPA 5.2, CH RoHS, CEL 1
Product color	Black
Compliance industry standards	DDC2B, DDC2B/CI
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package depth	114 mm
Package width	493 mm
Package height	422 mm
Package weight	3200 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	440 mm
Height (without stand)	346 mm
Weight (without stand)	2080 g
