AOC e960Swn User Manual

53
FL1,FL2,FL3,R106,R1
07,R133,R14,R142,R1
7,R177,R180,R181,R1
82,R183,R19,R201,R2
11,R214,R215,R216,R
217,R4,R72,R77,R81,
R88,R97
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R131,R132 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R1,R2 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R3 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R15,R213,R22,R74,R7
9
0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R94 0RH1301C422 1.3K OHM 1/16W 1608 1% D R/TP
R108,R90 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R83 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R42,R78 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R95 0RH1801C422 1.8K OHM 1/16W 1608 1% D R/TP
R137 0RH2000C422 200 OHM 1/16W 1608 1% D R/TP
R13 0RH2202C422 22K OHM 1/16W 1608 1% D R/TP
R20,R21,R61 0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R103,R212 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP
R41,R44 0RH2700C422 270 OHM 1/16W 1608 1% D R/TP
R89 0RH2702C422 27K OHM 1/16W 1608 1% D R/TP
R57,R60 0RH3001C422 3K OHM 1/16W 1608 1% D R/TP
R105 0RH3002C422 30K OHM 1/16W 1608 1% D R/TP
R49,R52,R62 0RH3301C422 3.3K OHM 1/16W 1608 1% D R/TP
R58 0RH3601C422 3.6K ohm, 1/16W(1608), 1 PER, D-Type, R/TP
R104 0RH3602C422 36K 1/16W 1% 1608
R84 0RH3901C422 3.9K OHM 1/16W 1608 1% D R/TP
R64,R65,R68 0RH4301C422 4.3K OHM 1/16W 1608 1% D R/PT
R85 0RH4703C422 470KOHM 1 / 16 W 1608 1% D R/TP
R69,R70,R71,R73 0RH5100C422 510 OHM 1/16W 1608 1% D R/TP
R82 0RH5102C422 51K OHM 1/16W 1608 1% D R/TP
R53,R56 0RH5601C422 5.6K OHM 1/16W 1608 1% D R/TP
R66,R87 0RH6200C422 620 OHM 1/16W 1608 1% D R/TP
R99 0RH6801C422 6.8K OHM 1/16W 1608 1% D R/TP
R46 0RH8201C422 8.2K OHM 1/16W 1608 1% D R/TP
R45,R48 0RH9100C422 910 OHM 1/16W 1608 1% D R/TP
R50,R54 0RH9101C422 9.1K OHM 1/16W 1608 1% D R/TP
AR11,AR12 0RHZL10005A 100OHM 5 1/16W 3216 R/TP
FL4 6200L-J015A BLM18PG300SN1D

AOC e960Swn Specifications

General

Aspect ratio	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	30 - 60 kHz
Display brightness (typical)	200 cd/m²
Display viewable area (HxV)	409.8 x 230.4 mm
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	TCO 5.2, CE/CB, cTUVus, FCC, CCC, EPA 5.2, CH RoHS, CEL 1
Product color	Black
Compliance industry standards	DDC2B, DDC2B/CI
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package depth	114 mm
Package width	493 mm
Package height	422 mm
Package weight	3200 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	440 mm
Height (without stand)	346 mm
Weight (without stand)	2080 g
