AOC F19S Service Manual

4
1. Monitor Specifications
LCD Panel
Model number F19s
Driving system TFT Color LCD
Viewable Image Size 470mm diagonal
Pixel pitch 0.3mm(H) x 0.3mm(V)
Video R, G, B Analog lnterface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 85.5 MHz
Resolution
Horizontal scan range 30 kHz - 80 kHz
Horizontal scan Size(Maximum) 409.8mm
Vertical scan range 55 Hz - 75 Hz
Vertical scan Size(Maximum) 230.4mm
Optimal preset resolution 1360 x 768 (60 Hz) or 1366 x 768 (60 Hz)
Highest preset resolution 1366 x 768 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM
Power Source 100-240VAC, 50/60Hz
Power Consumption
Active < 25 W
Standby < 1 W
Physical
Characteristics
Connector Type 15-pin Mini D-Sub
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base)
334.3 mm
Width
445.8 mm
Depth
130.1mm
Weight (monitor only)
3.7 kg
Weight (with packaging)
4.8 kg
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
Altitude:
Operating 0~ 3000m (0~ 10000 ft )
Non-Operating 0~ 5000m (0~ 15000 ft )
