OSD Setting
Basic and simple instruction on the control keys.
1) Press the -button to activate the OSD window.
2) Press< or >to navigate through the functions. Once the desired function is highlighted, press the -button
to activate it . press< or >to navigatethrough the sub-menu functions.Once the desired function is highlighted,
press -button to activate it.
3) Press< or >to change the settings of the selected function. Press to exit. If you want to adjust any other
function, repeat steps 2-3.
4) OSD Lock Function: To lock the OSD, press and hold the button while the monitor is off and then press
button to turn the monitor on. To un-lock the OSD - press and hold the button while the monitor is off
and then press button to turn the monitor on.
Notes:
1) If the product has only one signal input, the item of "Input Select" is disable to adjust.
2) ECO modes(except Standard mode), DCR, DCB mode and Picture Boost, for these four states that only
onestate can exist.
23

AOC G2260VWQ6 Specifications

General

Panel type	TN
Pixel pitch	0.248 x 0.248 mm
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	148.5 MHz
Display diagonal	21.5 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Viewable size, horizontal	477.5 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
Headphone out	Yes
DisplayPort version	1.2
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
HDMI cable length	1.8 m
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (average)	24 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Product color	Black, Red
Sustainability certificates	ENERGY STAR
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
Certification	TCO 6, TUV-GS, TUV-Bauart, FCC, CE, EAC, ISO, RoHS
Package type	Box
Package depth	435 mm
Package width	693 mm
Package height	127 mm
Package weight	4150 g
Feet color	Black
Front bezel color	Black/Red
Heavy metals free	Hg (mercury)
Market positioning	Gaming
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 144 Hz
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	184.4 mm
Width (with stand)	511.8 mm
Height (with stand)	376.9 mm
Weight (with stand)	3030 g
Depth (without stand)	- mm
Weight (without stand)	- g
