AOC G2590VXQ User Manual

Hotkeys
1 Source/Auto/Exit
2 Dial Point
3 Game Mode/Left
4 Image Ratio/Right
5 Power/ Menu/Enter
Power/Menu/Enter
Press the Power button to turn on the monitor.
When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 second to turn off the
monitor.
Dial Point
When there is no OSD, press Dial Point button to active Dial Point menu, and then press “Left” or “Right” to set Dial
Point on or off.
Game Mode/Left
When there is no OSD, press ”Left” key to open game mode function, then press ”Left” or “Right” key to select
game mode (FPS, RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.
Image Ratio/Right
When there is no OSD, press “Right” key to select continuously to change image ratio.
Source/Auto/Exit
When the OSD is closed, press Source/Auto/Exit button will be Source hot key function. When the OSD is closed,
press Source/Auto/Exit button continuously about 2 second to do auto configure (Only for the models with D-Sub).
21

AOC G2590VXQ Specifications

General

3D	-
Panel type	TN
Color depth	8 bit
Pixel pitch	0.2832 x 0.2832 mm
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	165 MHz
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	30 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	302.62 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	543.74 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	- Hz
Digital horizontal frequency	- kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
RMS rated power	4 W
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
HDMI cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Pivot angle	1 - 90 °
Tilt angle range	-3.5 - 21.5 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 75 Hz
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Package type	Box
Package depth	173 mm
Package width	627 mm
Package height	417 mm
Package weight	6620 g
Sustainability certificates	RoHS
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	179.5 mm
Height (with stand)	419.8 mm
Weight (with stand)	4300 g
Depth (without stand)	78.2 mm
Width (without stand)	558.6 mm
Height (without stand)	- mm
Weight (without stand)	- g
